拖链电缆
| SLK1800500高度无屏蔽拖链电缆 |  |
| 导线：多股超细精绞无氧铜丝，符合CDE0295CLASS 6标准
绝缘：特殊混合PVC绝缘
颜色代码：≤0.5mm 颜色表示，棕、黑、蓝、紫、粉红、橙
≥0.5mm 黑色数字白色号码编号，3芯以上带有蓝绿接地线（黄绿可选）
芯线结构：防扭结分层，或分组式间隙填充
护套材料：特殊改性PVC护套
护套颜色：黑色（RAL9005），灰色（RAL7001)，橙色（RAL2003） |
| 额定电压：截面＜0.5mm2:300/300V
截面≥0.5mm2:300/500V
测试电压：2000V
最小弯曲半径
固定敷设：6×D
移动安装：当行程<10米时，弯曲半径为8×D
当行程≥10米时，弯曲半径为10×D"
使用温度
固定敷设：-40℃至+90℃
移动安装：-30℃至+90℃
抗辐射强度：5×10^7cJ/kg
阻燃性：符合IEC60332-1-2+EN60332-1-2
耐油性：参见耐油性附表
耐化学性：参见耐化学性附表 |
| 移动特性◆敷设行程: 80m,加速度80m/S2,移动速度10m/S
◆弯曲寿命：50次/分钟,＞500万次
特性： ◆防浅水、防油、抗紫外线、耐候性
◆耐寒、耐磨性、能承受较重的机械外力
◆耐寒、耐磨性、能承受较重的机械外力 ◆符合认证RoHS |
| 适用于连续往复运动下的安装，特别是工业作用环境下的频繁弯曲场合，如现代化机械标准部件的拖链中及物流系统、操控系统、机械自动化系统等。数控机床、电子设备、五金冲压、木材石材机械、玻璃与门窗机械、注塑机、机械（人）手、建筑机械、重型机器厂、汽车制造、起重运输设备、自动化仓库、码头、消防车等的室内外环境。 |
| 型号 | 芯数及
截面积
mm2×nC | 近似外径
mm | 参考重量
kg/km | 型号 | 芯数及
截面积
mm2×nC | 近似外径
mm | 参考重量
kg/km |
| SLK1800500 | 0.08×2C | 3.6 | 17.4 | SLK1800500 | 0.3×3C | 5.0 | 39.1 |
| SLK1800500 | 0.08×3C | 3.7 | 20.7 | SLK1800500 | 0.3×4C | 5.4 | 48.0 |
| SLK1800500 | 0.08×4C | 4.0 | 24.7 | SLK1800500 | 0.3×36C | 15.5 | 344.4 |
| SLK1800500 | 0.08×36C | 10.6 | 152.4 | SLK1800500 | 0.4×2C | 5.1 | 36.9 |
| SLK1800500 | 0.1×2C | 4.2 | 22.6 | SLK1800500 | 0.4×3C | 5.4 | 46.6 |
| SLK1800500 | 0.1×3C | 4.4 | 27.3 | SLK1800500 | 0.4×4C | 5.9 | 57.6 |
| SLK1800500 | 0.1×4C | 4.7 | 32.9 | SLK1800500 | 0.4×36C | 17.3 | 425.2 |
| SLK1800500 | 0.1×36C | 13.1 | 216.2 | SLK1800500 | 0.5×2C | 5.1 | 39.7 |
| SLK1800500 | 0.15×2C | 4.3 | 24.6 | SLK1800500 | 0.5×3C | 5.4 | 50.9 |
| SLK1800500 | 0.15×3C | 4.5 | 30.0 | SLK1800500 | 0.5×4C | 6.0 | 63.5 |
| SLK1800500 | 0.15×4C | 4.7 | 34.0 | SLK1800500 | 0.5×36C | 18.1 | 485.3 |
| SLK1800500 | 0.15×36C | 13.4 | 239.0 | SLK1800500 | 0.75×2C | 5.8 | 50.2 |
| SLK1800500 | 0.2×2C | 4.4 | 27.0 | SLK1800500 | 0.75×3C | 6.2 | 64.8 |
| SLK1800500 | 0.2×3C | 4.7 | 33.2 | SLK1800500 | 0.75×4C | 6.8 | 81.1 |
| SLK1800500 | 0.2×4C | 5.1 | 40.5 | SLK1800500 | 0.75×36C | 20.3 | 628.9 |
| SLK1800500 | 0.2×36C | 14.1 | 273.6 | SLK1800500 | 1.0×2C | 6.3 | 70.4 |
| SLK1800500 | 0.3×2C | 4.7 | 31.3 | SLK1800500 | 1.0×3C | 6.7 | 86.6 |
| SLK1800500 | 1.0×4C | 7.3 | 106.8 | SLK1800500 | 6.0×2C | 13.0 | 322.9 |
| SLK1800500 | 1.0×36C | 22.3 | 801.9 | SLK1800500 | 6.0×3C | 13.9 | 409.0 |
| SLK1800500 | 1.5×2C | 7.7 | 102.2 | SLK1800500 | 6.0×4C | 15.4 | 514.1 |
| SLK1800500 | 1.5×3C | 8.2 | 125.7 | SLK1800500 | 6.0×18C | 30.4 | 2038.4 |
| SLK1800500 | 1.5×4C | 9.0 | 155.3 | SLK1800500 | 8.0×2C | 15.1 | 432.2 |
| SLK1800500 | 1.5×36C | 28.2 | 1181.7 | SLK1800500 | 8.0×3C | 16.2 | 547.8 |
| SLK1800500 | 2.0×2C | 9.6 | 155.8 | SLK1800500 | 8.0×4C | 18.0 | 689.3 |
| SLK1800500 | 2.0×3C | 10.2 | 192.4 | SLK1800500 | 8.0×5C | 19.9 | 839.0 |
| SLK1800500 | 2.0×4C | 11.3 | 239.0 | SLK1800500 | 8.0×6C | 22.0 | 994.2 |
| SLK1800500 | 2.0×20C | 23.4 | 1007.8 | SLK1800500 | 10.0×2C | 16.0 | 501.3 |
| SLK1800500 | 2.5×2C | 10.0 | 172.2 | SLK1800500 | 10.0×3C | 17.2 | 639.1 |
| SLK1800500 | 2.5×3C | 10.7 | 212.9 | SLK1800500 | 10.0×4C | 19.1 | 806.3 |
| SLK1800500 | 2.5×4C | 11.9 | 264.9 | SLK1800500 | 10.0×5C | 21.2 | 982.8 |
| SLK1800500 | 2.5×25C | 28.4 | 1430.7 | SLK1800500 | 10.0×6C | 23.4 | 1165.4 |
| SLK1800500 | 4.0×2C | 11.6 | 242.0 | SLK1800500 | 16.0×2C | 18.8 | 727.6 |
| SLK1800500 | 4.0×3C | 12.4 | 302.4 | SLK1800500 | 16.0×3C | 20.2 | 937.3 |
| SLK1800500 | 4.0×4C | 13.6 | 371.2 | SLK1800500 | 16.0×4C | 22.4 | 1188.1 |
| SLK1800500 | 4.0×20C | 28.5 | 1619.7 | SLK1800500 | 16.0×5C | 24.9 | 1451.8 |
| | | | | SLK1800500 | 16.0×6C | 27.5 | 1724.2 |
| 型号 | 对数 | 芯数及截面积mm2Xn | 近似外径 | 参考重量Kg/Km | 型号 | 对数 | 芯数及截面积mm2Xn | 近似外径 | 参考重量Kg/Km |
| SLK1941500 | 2对 | 0.1×4C | 8.2 | 72.7 | SLK1941500 | 2对 | 0.4×4C | 10.4 | 113.6 |
| SLK1941500 | 3对 | 0.1×2C | 8.8 | 88.2 | SLK1941500 | 3对 | 0.4×6C | 11.2 | 142.7 |
| SLK1941500 | 4对 | 0.1×8C | 9.9 | 113.6 | SLK1941500 | 4对 | 0.4×8C | 12.6 | 183.6 |
| SLK1941500 | 16对 | 0.1×32C | 16.1 | 284.5 | SLK1941500 | 16对 | 0.4×32C | 21.5 | 513.6 |
| SLK1941500 | 2对 | 0.2×4C | 8.4 | 77.3 | SLK1941500 | 2对 | 0.5×4C | 11.0 | 127.3 |
| SLK1941500 | 3对 | 0.2×6C | 9.0 | 94.5 | SLK1941500 | 3对 | 0.5×6C | 11.9 | 160.0 |
| SLK1941500 | 4对 | 0.2×8C | 10.1 | 121.8 | SLK1941500 | 4对 | 0.5×8C | 13.3 | 206.4 |
| SLK1941500 | 16对 | 0.2×32C | 16.6 | 311.8 | SLK1941500 | 16对 | 0.5×32C | 23.0 | 592.7 |
| SLK1941500 | 2对 | 0.25×4C | 9.2 | 90.9 | SLK1941500 | 2对 | 0.75×4C | 11.9 | 150.0 |
| SLK1941500 | 3对 | 0.25×6C | 9.9 | 111.8 | SLK1941500 | 3对 | 0.75×6C | 12.7 | 190.0 |
| SLK1941500 | 4对 | 0.25×8C | 11.2 | 144.5 | SLK1941500 | 4对 | 0.75×8C | 14.3 | 245.5 |
| SLK1941500 | 16对 | 0.25×32C | 18.6 | 382.7 | SLK1941500 | 16对 | 0.75×32C | 25.0 | 730.9 |
| SLK1941500 | 2对 | 0.3×4C | 9.2 | 91.8 | SLK1941500 | 2对 | 1.0×4C | 13.7 | 200.0 |
| SLK1941500 | 3对 | 0.3×6C | 9.9 | 112.7 | SLK1941500 | 3对 | 1.0×6C | 14.4 | 243.6 |
| SLK1941500 | 4对 | 0.3×8C | 11.2 | 146.4 | SLK1941500 | 4对 | 1.0×8C | 15.9 | 303.6 |
| SLK1941500 | 16对 | 0.3×32C | 18.6 | 390.9 | SLK1941500 | 16对 | 1.0×32C | 28.4 | 935.5 |
